RICOH Interactive Whiteboard Specifications

Display Specifications

• Screen Size: Available in 55-inch, 65-inch, and 75-inch models
• Resolution: 4K Ultra HD (3840 x 2160 pixels)
• Display Type: LCD with LED backlight
• Brightness: 350 cd/m² (typical)
• Touch Technology: Multi-touch (up to 20 simultaneous touch points)
• Touch Sensitivity: Precise and responsive to pen, finger, and touch gestures
• Aspect Ratio: 16:9
• Viewing Angle: 178° horizontal and vertical

Connectivity

• Wireless Connectivity:
  • Wi-Fi (IEEE 802.11a/b/g/n/ac)
  • Bluetooth 4.0
  • NFC (Near Field Communication)
• Wired Connectivity:
  • HDMI (2 ports)
  • USB Type-A (2 ports)
  • USB Type-B (for touch interface)
  • Ethernet (LAN) port
  • VGA (1 port)
  • Audio In/Out (3.5mm)
• Screen Mirroring:
  • AirPlay (for iOS devices)
  • Miracast (for Android/Windows devices)
  • Chromecast support
• Cloud Storage Integration: Google Drive, Microsoft OneDrive, Dropbox, Box

Interactive Features

• Touch Points: Supports up to 20 simultaneous touch points for collaborative use
• Pen/Marker Functionality: Includes digital pens with color and thickness variations, and interactive annotation tools
• Screen Annotation: Ability to draw, highlight, and write directly on the screen, both during presentations and content sharing
• Digital Whiteboard: Allows for multiple pages of notes, drawings, and annotations that can be saved or exported

Audio and Video

• Speakers: Built-in stereo speakers (10W + 10W)
• Microphone: Built-in microphone for video conferencing
• Camera: Integrated 1080p camera for video conferencing (optional with some models)

Software and Application Support

• Pre-installed Software: Includes RICOH interactive software for whiteboarding, collaboration, and document sharing
• Compatible Software: Supports common business tools such as Microsoft Office, Google Workspace, and other collaborative platforms
• Cloud Services Integration: Seamlessly integrates with cloud-based tools for file sharing, annotation, and collaboration
• Operating System: Android-based platform for smooth operation and easy integration with other devices

Mounting and Installation

• Mounting Type: Wall-mounted or stand (optional)
• VESA Mount Compatible: Yes, with 600 x 400mm mounting holes
• Installation: Plug-and-play setup, with minimal configuration required

Energy Efficiency

• Power Consumption:
  • On: 150W
  • Standby: Less than 0.5W
• Power Supply: AC 100-240V, 50/60Hz
• Energy Star Certified: Yes

Security Features

• User Authentication: Optional user authentication with NFC or PIN
• Data Encryption: Supports secure communication protocols for data transfer and storage
• Password Protection: Ability to set administrative passwords to limit access to settings

Dimensions and Weight

• Dimensions (W x H x D):
  • 55″ model: 1251 x 743 x 80 mm (49.2 x 29.3 x 3.1 inches)
  • 65″ model: 1481 x 884 x 80 mm (58.4 x 34.8 x 3.1 inches)
  • 75″ model: 1690 x 991 x 80 mm (66.5 x 39.0 x 3.1 inches)
• Weight:
  • 55″ model: 25 kg (55 lbs)
  • 65″ model: 35 kg (77 lbs)
  • 75″ model: 50 kg (110 lbs)

Optional Accessories

• Mobile Stand: Adjustable stand for flexible positioning
• Camera and Audio Kit: Optional high-definition camera and microphone for enhanced video conferencing
• Touch Pens: Additional digital pens for multiple users

The RICOH Interactive Whiteboard provides a comprehensive suite of features designed for seamless collaboration, making it an essential tool for modern workplaces and educational environments. With high-quality visuals, versatile connectivity, and powerful interactive features, it enhances productivity and communication across teams and individuals.
